1. It has a unique stable flow structure;

2. The feeding screw and measuring screw are synchronously adjusted for speed, with real weight signals and high measurement accuracy;


3. The spiral blades are made of precision processed manganese steel material, which has strong wear resistance and long service life;


4. Adopting a sealed structure to reduce dust emission;


5. If the output is ≥ 55T/H, please use a double tube spiral scale;


6. Support non-standard customization for customers.


Technical parameters of spiral scale:


1. Measurement accuracy: Level 2.0


2. Control accuracy: better than 1%


3. Weighing range: 0-100t/h


4. Spiral speed: 40~85r/min


5. Spiral diameter: Φ 100~ Φ four hundred


6. Power supply: Control system: single-phase 220V ± 10%, 50HZ


Power system: three-phase 380V ± 10%, 50HZ


7. Usage environment:


Temperature: minus ten degrees Celsius to forty degrees Celsius


Humidity: 5-90%


Venue: No strong electromagnetic fields or strong vibrations
